Description:CAZ oil-resisting non-asbestos sheet is made from Kevla fiber, synthetic rubber, filling material and dye, compressed and calendered under high temperature and pressure into a sheet form. It eliminates asbestos-rubber sheet essentially and thoroughly.
Non-asbestos Sheet
|
Item |
Style AF144N- |
|
200 |
300 |
350 |
|
Density g/cm3 |
1.7~1.9 |
1.7~1.9 |
1.7~1.9 |
|
Tensile strength¡ÝMpa |
8 |
11 |
12 |
|
Compressibility ¡Ý% |
12¡À5 |
12¡À5 |
12¡À5 |
|
Recovery ¡Ý% |
45 |
50 |
50 |
|
Stress relaxation ¡Ü% |
45 |
45 |
45 |
|
20# aviation lub oil for 150¡æ*5h |
Thickness increase ¡Ü |
18 |
15 |
15 |
|
Weight increase¡Ü |
20 |
16 |
16 |
|
ASTM No.3#-5H 150¡æ |
Thickness increase ¡Ü |
20 |
20 |
20 |
|
Weight increase¡Ü |
18 |
14 |
14 |
|
Tmax: ¡æ |
200 |
300 |
350 |
|
Pmax: Mpa |
2.0 |
3.0 |
3.5 |
|
Resistance
to media |
Oil fuel, gases, salt solutions and many other media. |
|
Dimension |
1500x4000mm£»1270x3810mm
Thickness: 0.5~5mm |
Available colour: Black with some white, Red or Green-white, etc.;
Available with tin steel, copper, SS304 etc. wire mesh insertion (AF144NI);
Also available with anti-stick or graphite coating (AF144S or G).
|
